Double Wall Corrugated Pipe Making Machine with Precision Temperature Control Modular Design and Online Belling
무료 샘플과 쿠폰을 받으려면 연락하세요.
왓츠앱:0086 18588475571
웨이 채팅: 0086 18588475571
스카이프: sales10@aixton.com
걱정이 있으시면 24시간 온라인 서비스를 제공합니다.
x제품 상세 정보
| 원료 | PE, PP, HDPE/PP, PVC | 파이프 범위 | 32-1600mm |
|---|---|---|---|
| 사용 | 플라스틱 파이프 제작 | 파이프 레이어 | 단일 벽, 이중 벽, 멀티 벽 |
| 유형 | 표준 또는 사용자 정의 | 특징 | 높은 생산성, 경쟁 가격, 에너지 절약, 자동 |
| 애플리케이션 | 배수관, 시립 공학, 지하 하수관, 전기 케이블 도관 | 제어 개념 | plc |
| 강조하다 | 32-1600mm Double Wall Corrugated Pipe Making Machine,Energy Saving Corrugated Pipe Production Line,Drainage Pipe PVC Pipe Extrusion Line |
||
필요한 제품을 선택하고 게시판에서 당사와 소통 할 수 있습니다.
제품 설명
PE / PVC Double Wall Corrugated Pipe Making Machine Featuring High Productivity
Product Description
The PVC/PE/MPP corrugated Pipe production line features two single-screw extruders for simultaneous extrusion of inner and external plastic layers. Our precision temperature control system and optimized screw design ensure uniform plasticization and stable flow for high-speed production.
The pipe head incorporates a precision flow channel design for efficient lamination of inner and outer plastic layers, guaranteeing uniform wall thickness, high concentricity, and resistance to delamination. The modular design enables rapid switching between multiple pipe diameters while maintaining dimensional accuracy and structural stability during high-speed operation.
This 3rd generation double wall corrugated pipe line from Shandong HUASU delivers 20-40% increased output and production speed compared to previous models. The system includes online belling capability and utilizes Siemens PLC for efficient control and management.
Key Features
- Pressure water-cooling for mould blocks enhances production speed
- Low energy consumption reduces production costs
- Efficient vacuum system ensures flawless pipe production
- Precision mould block temperature control optimizes pipe quality
- Quick interchangeability between different mould sizes
- Fully automated extrusion line operation
- Synchronized corrugator and extruder performance
- Hardened screws and barrels for extended durability
- Remote service capability for added convenience
Technical Specifications
| Parameter | Description |
|---|---|
| Pipe Layers | Single Wall, Double Wall, Multi Wall |
| Application | Drainage Pipe, Municipal Engineering, Underground Sewage Pipe, Electric Cable Conduit |
| Electric Components | Siemens |
| Control Concept | PLC |
| Features | High Productivity, Competitive Price, Energy Saving, Automatic |
| Cooling Type | Air Or Water Cooling |
| Raw Material | PE, PP, HDPE/PP, PVC |
| Used For | Making Plastic Pipe |
| Type | Standard Or Customized |
| Max. Line Speed | 3-15m/min |
Applications
Our advanced pipe making machine produces high-quality plastic pipes for water supply, drainage systems, and electric cable conduits. Engineered to meet strict industry standards, these durable pipes are ideal for municipal engineering projects, water transportation networks, and underground cable protection systems.
