High-Speed Double Wall Corrugated Pipe Extrusion Line 32-1600mm
| 브랜드 이름 | HUASU |
|---|---|
| 인증 | CE,ISO |
| Model Number | SBG |
| Minimum Order Quantity | 1 Line |
| 가격 | 10K-1000K |
| Packaging Details | Standard Seaworthy Packing |
| Delivery Time | 30-90 Days |
| Payment Terms | T/T,L/C |
| Supply Ability | 100 Line |
무료 샘플과 쿠폰을 받으려면 연락하세요.
왓츠앱:0086 18588475571
웨이 채팅: 0086 18588475571
스카이프: sales10@aixton.com
걱정이 있으시면 24시간 온라인 서비스를 제공합니다.
x제품 상세 정보
| Capacity | 150-2000kg/h | Production Power | 100-1000kW |
|---|---|---|---|
| Used Condition | 220-420V/3phase | Control System | PLC Control |
| After Sales Service | Engineers Availiable To Serive | Pipe Diameter | 32-1600mm |
| Plastic Machine | Double Wall Corrugated Pipe Extrusion Line | Pipe materials | PVC / PE / MPP / PA / HDPE |
| 강조하다 | high-speed corrugated pipe extrusion line,double wall plastic pipe extruder,32-1600mm pipe extrusion machine |
||
제품 설명
High-Speed Double Wall Corrugated Pipe Extrusion Line 32-1600mm
Product Specifications
| Capacity | 150-2000kg/h |
| Production Power | 100-1000kW |
| Used Condition | 220-420V/3phase |
| Control System | PLC Control |
| After Sales Service | Engineers Available To Service |
| Pipe Diameter | 32-1600mm |
| Plastic Machine | Double Wall Corrugated Pipe Extrusion Line |
| Pipe Materials | PVC / PE / MPP / PA / HDPE |
Product Overview
The double wall corrugated pipe line represents the third generation upgraded product from Shandong HUASU plastic technology Co.LTD. This latest version features significant improvements, with extruder output and pipe production speed enhanced by 20-40% compared to previous models. These advancements enable seamless online belling while ensuring premium quality and performance.
The system incorporates Siemens PLC technology for reliable industrial automation, ensuring smooth operation and precise control throughout the production process to enhance overall performance and productivity.
Key Features
- Pressure water-cooling for mold blocks significantly enhances production speed
- Minimal energy consumption effectively reduces production costs
- Efficient vacuum system ensures flawless pipe production
- Optimized temperature control system improves pipe quality and appearance
- Quick changeover between mold sizes with compatible tooling
- Fully automated complete extrusion line operation
- Synchronously controlled corrugators and extruders for smooth operation
- Hardened treated screws and barrels for increased durability
- Available remote service option for added convenience
Technical Parameters
| Production Power | 100-1000kW |
| Capacity | 150-2000kg/h |
| Port | Qingdao |
| After Sales Service | Engineers Available To Service |
| Pipe Diameter | 32-1600mm |
| Used Condition | 220-420V/3phase |
| Pipe Materials | PVC / PE / MPP / PA / HDPE |
Applications
Our plastic pipe making machine produces pipes for various applications including water supply, drainage, and electric cable conduits. Designed to create high-quality pipes meeting industry standards, it accommodates diverse sizes and configurations to satisfy specific requirements.
Whether for domestic water networks, commercial drainage solutions, or industrial cable conduits, our machine provides efficient and reliable manufacturing capabilities to meet your needs.
