원래 장소:
중국
브랜드 이름:
Shandong Huasu Brand
인증:
CE, ISO9001
모델 번호:
DWC 관 밀어남 선
HDPE 400 Corrugated Pipe Machine HDPE 400 Pipe Extruder HDPE 400 Production Line
| NO. | Inner Diameter( mm) | Outside Diameter ( mm) | Remark |
| 1 | 110 | ||
| 2 | 125 | ||
| 3 | 140 | ||
| 4 | 160 | ||
| 5 | 180 | ||
| 6 | 200 | ||
| 7 | 225 | ||
| 8 | 250 | ||
| 9 | 280 | ||
| 10 | 315 | ||
| 11 | 355 | ||
| 12 | 400 |
| Location | Workshop |
| Power Supply | No dangerous area, No power stop area |
| Humidity degree | ≤95% |
| Temperature | 0-36℃ |
| Power | 380 V x 50 Hz x 3 Phase |
| Total Power | 250kw |
| Cooling Water | Recycling water.≤20℃, ≥0.3Mpa, ～9M3/h |
| Compressed air | 0.3m3/min, ＞1.5Mpa |
| Line Dimension | 47 m *2.7 m * 2.5 m |
| Extruder | Motor | Max Output | Note |
| SJ90/33 | 132kw | 300-450kg/h | |
| SJ30/25 | 1.5kw | 5-10kg/h |
Our double wall corrugated pipe extrusion line can make below pipes:
1. Size: DN16-1600mm (Can Be Customized).
2.Pressure Rating: SDR 41-PN 4, SDR 33-PN 5, SDR 26-PN 6, SDR 21-PN 8, SDR 17-PN 10, SDR 13.6-PN 12.5, SDR 11-PN 16, SDR 9-PN 20, SDR 7.4-PN 25, SDR 6-PN 32.
3.Life: 70 Years.
4.Raw Materials: PE80, PE100, PE4710.
5.Certificate: ISO 14001, ISO 9001, OHSAS 18001, CE BS EN 12201, WRAS Certification.
